2020 Can-Am Outlander™ 650

PERFORMANCE BEYOND ITS PRICE.

The most capable Outlander ever, with wider stance, better handling & class-leading power for jobs and thrilling rides alike.

Highlights* Rotax® V-twin engine options
* New arched double A-arm front suspension with front sway bar
* Continuously Variable Transmission (CVT) with engine braking
* Surrounding Spar Technology (SST) G2 frame with Geometric Contact Control
* Torsional Trailing arm Independent (TTI) rear suspension
* Visco-Lok® auto-locking front differential
* 230-W lighting from headlights
* High-strength, multifunction racks with LinQ™ quick-attach accessory system
* 5.7-gal (21.4 L) water-resistant rear compartment
* RF Digitally Encoded Security System (D.E.S.S.™)
* Multifunction digital gauge

Engines* Type: 62 hp, Rotax 649.6 cc V-twin, liquid cooled
* Fuel Delivery System: Electronic Fuel Injection (EFI)
* Transmission: CVT, P / R / N / H / L, standard engine braking
* Drive Train: Selectable 2WD / 4WD with Visco-Lok auto-locking front differential

Suspensions* Front Suspension: Arched double A-arm with front sway bar 9.2 in. (23.3 cm) travel
* Front Shocks: Oil
* Rear Suspension: Torsional Trailing arm Independent (TTI) 9.9 in. (25.1 cm) travel
* Rear Shocks: Oil

Brakes* Front: Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
* Rear: Single 214 mm ventilated disc brake with hydraulic twin-piston caliper

Features* Gauge: Multifunction digital: Speedometer, tachometer (bar graph RPM, bottom bar numerical RPM), odometer, trip & hour meters, diagnostic center, gear position, engine hour meter, 4 x 4 indicator, temperature and engine lights, fuel gauge, clock
* Instrumentation: Lighter type DC outlet in console, standard connector in the back (15-A)
* Lighting: 230 W from twin 60-W projectors and dual 55-W reflectors with tail light / brake light
* Winch: Prewired for available winch
* Protection: Mudguards
* Seat: Standard
* Anti-theft System: RF Digitally Encoded Security System (D.E.S.S.)

Tires / Wheels* Front Tires: Carlisle® ACT radial 26 x 8 x 12 in. (66 x 20.3 x 30.5 cm)
* Rear Tires: Carlisle ACT radial 26 x 10 x 12 in. (66 x 25.4 x 30.5 cm)
* Wheels: 12-in. steel

Dimensions / Capacities* L x W x H: 86 x 48 x 49.5 in. (218.4 x 121,9 x 126 cm)
* Wheelbase: 51 in. (129.5 cm)
* Ground Clearance: 11 in. (27.9 cm)
* Dry Weight: 749 lb (341 kg)
* Rack Capacity Front: 100 lb (45 kg)
* Rack Capacity Rear: 200 lb (90 kg)
* Storage Capacity: Rear: 5.7 gal (21.4 L)
* Towing capacity: 1,650 lb (750 kg)
* Fuel Capacity: 5.4 gal (20.5 L)
* Seat Height: 34.5 in. (87.7 cm)

Warranty* Factory: 6-months limited warranty
* Extended: Up to 36 months B.E.S.T. coverage
NOTES:\*Base model dry weight shown.
PERFORMANCE BEYOND ITS PRICE.

The most capable Outlander ever, with wider stance, better handling & class-leading power for jobs and thrilling rides alike.

Highlights* Rotax® V-twin engine options
* New arched double A-arm front suspension with front sway bar
* Continuously Variable Transmission (CVT) with engine braking
* Surrounding Spar Technology (SST) G2 frame with Geometric Contact Control
* Torsional Trailing arm Independent (TTI) rear suspension
* Visco-Lok® auto-locking front differential
* 230-W lighting from headlights
* High-strength, multifunction racks with LinQ™ quick-attach accessory system
* 5.7-gal (21.4 L) water-resistant rear compartment
* RF Digitally Encoded Security System (D.E.S.S.™)
* Specifications
--------------

**Engine Type**
62 hp, Rotax 649.6 cc V-twin, liquid cooled

**Displacement**
649.6 cc

**Engine Cooling**
Liquid

**Fuel System**
Electronic Fuel Injection (EFI)

**Front Suspension**
Arched double A-arm with front sway bar

**Front Travel**
9.2 in. (23.3 cm)

**Front Brake Type**
Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers

**Front Tires**
Carlisle® ACT radial 26 x 8 x 12 in. (66 x 20.3 x 30.5 cm)

**Rear Travel**
9.9 in. (25.1 cm)

**Rear Suspension**
Torsional Trailing arm Independent (TTI)

**Rear Brake Type**
Single 214 mm ventilated disc brake with hydraulic twin-piston caliper

**Rear Tires**
Carlisle ACT radial 26 x 10 x 12 in. (66 x 25.4 x 30.5 cm)

**Dry Weight**
749 lb. (341 kg)

**Front Rack Capacity**
100 lb. (45 kg)

**Rear Rack Capacity**
200 lb. (90 kg)

**Towing Capacity**
1,650 lb. (750 kg)

**Fuel Capacity**
5.4 gal (20.5 L)

**Ground Clearance**
11 in. (27.9 cm)

**Machine Dimensions (LxWxH)**
86 x 48 x 49.5 in. (218.4 x 121.9 x 126 cm)

**Wheelbase**
51 in. (129.5 cm)

**Drive Train**
Selectable 2WD / 4WD with Visco-Lok auto-locking front differential

**Transmission**
CVT, P / R / N / H / L, standard engine braking

**Speedometer**
Digital

**Tachometer**
Digital

**Odometer**
Digital

**Lighting**
230 W from twin 60-W projectors and dual 55-W reflectors with tail light / brake light

**Colors**
Viper Red

**Warranty**
Factory: 6-months; Extended: Up to 36 months B.E.S.T. coverage
